SX Crossed Roller Bearings

SX Crossed Roller Bearings

Drawing

Datasheet

Bearing No.	Dimensions						Mass
Bearing No.	d	D	Dpw	BB1	S	r
–	mm	mm	mm	mm	mm	mm	kg
SX011814	70	90	80	10	1.2	0.6	0.3
SX011818	90	115	102	13	1.2	1	0.4
SX011820	100	125	112	13	1.2	1	0.5
SX011824	120	150	135	16	1.5	1	0.8
SX011828	140	175	157	18	1.5	1.1	1.1
SX011832	160	200	180	20	1.5	1.1	1.7
SX011836	180	225	202	22	2	1.1	2.3
SX011840	200	250	225	24	2	1.5	3.1
SX011848	240	300	270	28	2	2	5.3
SX011860	300	380	340	38	2.5	2.1	12
SX011868	340	420	380	38	2.5	2.1	13.5
SX011880	400	500	450	46	2.5	2.5	24
SX0118/500	500	620	560	56	2.5	3	44
